THE ENERGETICS INDUSTRIES UNQUESTIONED
#1 MIXING & BLENDING TECHNOLOGY OF CHOICE
The emergence of Resodyn Acoustic Mixers, Inc. was a direct result of its technological superiority regarding the mixing of energetic materials for the manufacturing of munitions, propellants, explosives, and pyrotechnics.
Next generation explosive mixing is a new method of mixing explosives that uses sound waves instead of blades.This process is called Resonant Acoustic Mixing (RAM).
- Increased power: RAM can increase the explosive power of munitions by up to 20%.
- Reduced mixing time: RAM can mix explosives faster than traditional methods, reducing the amount of time and energy required.
- Reduced waste: RAM can reduce the amount of waste generated during mixing.
- Improved safety: RAM can reduce the risk of explosion by eliminating the need for mechanical mixers.
- Improved performance: RAM can improve the performance of explosives, including their mechanical, safety, and aging properties.
- Warheads: RAM can be used to create more powerful warheads.
- Artillery: RAM can be used to create more powerful artillery shells.
- Demolition: RAM can be used to create demolition explosives that can be used in all weather conditions.
ResonantAcoustic® Mixing (RAM) systems deliver the highest safety standards, while providing industry leading process, quality, and performance. RAM offers thorough mixing dispersion of energetic materials and unequalled uniformity via its unique bladeless design.
Repeatability of ultra-high processing results, material compatibility and efficiencies are critical elements to the development of energetic mixing materials. Incorporation of RAM mixing systems into energetic manufacturing processes provides all of the aforementioned qualities, and delivers 10X to 100X processing time acceleration with ease of scalability for mass production, to include continuous processing.
INDUSTRY EXPERT
TESTIMONIALS
“RAM is promising route for primer formulation processing. It minimizes safety concerns with mixing, and exhibits great potential for dry mixing…”
- Materials Scientist at a major U.S. government agency
“...[RAM] allows us to obtain a better quality of the final mixtures in a reduced amount of time. Some exciting work is also being performed on propellant while using this vanguard technology, and very promising results obtained.”
- Roxel Group, a propulsion systems company
“Acoustic energy delivers efficient energy transfer...[and] reduces mixing time: hours to minutes, minutes to seconds. [We] mix in sealed vessels—waste reduction! No impellers, blades, or shafts. RAM vessels are easy to clean out and transfer materials.”
- Munitions Engineer at U.S. Dept. of Defense
“Our engineers have achieved a 20 percent increase in munition explosive mixing current polymer bonded explosives using the Resodyn Acoustic Mixer. ”
- BAE Systems Inc.
Richard Brown
Head of Technology Communications
THE UNIVERSAL
MIXING SOLUTION
The ResonantAcoustic® Mixer (RAM) product line harnesses the power of resonance (low-frequency sound) to generate powerful and efficient energetic mixing of complex Solid-Solid, Solid-Liquid, Liquid-Gas, and Liquid-Liquid Blends. RAM systems provide;
- 10-100X faster mixing times
- bladeless non-contact mixing
- consistent homogenization
- remote control operation
- repeatable
- scalable
- durable
- custom engineered systems
- reliable
- cost saving
- eco-friendly operation
- unmatched safety
Client Testimonial - THE FALCON PROJECT, LTD
Rocket Motor Static Fire: Composite Propellant made with RAM by The Falcon Project LTD UK
Static fire of a 49 kg composite propellant rocket motor made with RAM:
Boost - Sustained Thrust Profile
ResonantAcoustic® Mixing Energetics Video
ResonantAcoustic® Mixing is the unquestioned #1 Energetics, Explosive, Rocket Propellant, Pyrotechnic and Ammunition Materials mixing, coating and milling choice globally
Client Testimonial Video - BAE
BAE uses RAM to mix explosive materials with higher solids loading that are too viscous to mix with conventional mixers.
Click the image to visit the BAE Systems Next Generation Explosive Mixing Page with ResonantAcoustic Mixing video near the bottom of their page.
Extended Client Testimonial Video - SERDP / ESTCP
The Strategic Environmental Research and Development Program (SERDP) and the Environmental Security Technology Certification Program (ESTCP) have been utilizing RAM Technology for several projects.
This particular project demonstrates the ability of the Resonant Acoustic® Mixing (RAM) technology to produce energetic weapons systems components in a single processing step and quantify the reduction in processing waste generated as compared to legacy manufacturing techniques.
Loaded Polymer Blending in Less than 3 Minutes!
To illustrate a heavily loaded polymer blend, two materials of very different particle sizes are blended with a polymer surrogate. This footage documents the nature of the material blending and integration into a heavily loaded (~85%) polymer based paste in just over 2 minutes! The use of RAM™ technology is ideally suited for loading of solids into polymers and mixing to a high rate of dispersion and consistent viscosity throughout the blend.
Articles on Energetics Mixing
Effect of resonant acoustic powder mixing on delay time of W–KClO4–BaCrO4 mixtures
APL Materials
"By comparing the thermal conductivity of WKB mixtures mixed manually and using an acoustic powder mixer, we found that acoustic powder mixing resulted in minimal deviations in thermal conductivity, proving more uniform mixing."
Kwon, K., Ryu, S., Joo, S., Han, Y., Baek, D., Park, M., Kim, D., & Hong, S. (2024). Effect of resonant acoustic powder mixing on delay time of W–KClO4–BaCrO4 mixtures. APL Materials, 12(3). https://doi.org/10.1063/5.0194888
Study on the control of flow field by resonance acoustic mixing technology for purification of high performance spherical HATO crystals
Separation and Purification Technology
"The spheroidization of HATO has been achieved in an environmentally friendly manner by resonance acoustic mixing assisted solvent erosion technology, effectively improving its thermal properties, mechanical sensitivity, and the mechanical properties of HATO explosive columns."
Liao, D., Cao, H., Li, S., Cheng, W., Yan, X., & An, C. (2024). Study on the control of flow field by resonance acoustic mixing technology for purification of high performance spherical HATO crystals. Separation and Purification Technology, 339, 126688. https://doi.org/10.1016/j.seppur.2024.126688
Novel Solid Propellants Enabled Through In Situ Martian Perchlorates
Journal of Propulsion and Power
"Three propellants made from Martian perchlorates were manufactured and compared to a control propellant with AP as the oxidizer... Mixing was carried out using a LabRAM I benchtop mixer..."
Hoganson, A. C. C., Afriat, A., Wernex, C. M., Ferguson, R. E., Rathore, H., Patel, D. N., Tappan, B., & Son, S. F. (2024). Novel solid propellants enabled through in situ martian perchlorates. Journal of Propulsion and Power, 40(3), 388–396. https://doi.org/10.2514/1.b39269
A review on the preparation and characterization methods of spherical explosive crystals
Journal of Materials Research and Technology
"Then, the RDX crystal particles with a sphericity greater than 90 % were prepared by resonance acoustic mixing assisted solvent erosion technology. Compared with the raw RDX, the thermal performance and safety performance of spherical RDX crystals were improved."
Liao, D., Li, M., Wang, J., Zhang, M., Qiu, M., & An, C. (2023). A review on the preparation and characterization methods of spherical explosive crystals. Journal of Materials Research and Technology, 27, 3098–3118. https://doi.org/10.1016/j.jmrt.2023.10.146
Microstructural investigation of PBX 9501: Comparing wet slurry and resonant acoustic mixing techniques
AIP Conference Proceedings
"These initial results suggest that differences in the microstructure do exist between PBX 9501 prepared via wet slurry and LabRAM mixing. Greater homogeneity in the binder prepared with LabRAM was confirmed by μCT and resulted in consistently higher densities when pressed under the same conditions."
Duque, A. L., Hill, L. G., Tisdale, J. T., Gielata, J. A., Mang, J. T., & Patterson, B. M. (2023). Microstructural investigation of PBX 9501: Comparing wet slurry and resonant acoustic mixing techniques. AIP Conference Proceedings, 2844, 300007. https://doi.org/10.1063/12.0020414
Mixing Characteristics and Parameter Effects on the Mixing Efficiency of High-Viscosity Solid–Liquid Mixtures under High-Intensity Acoustic Vibration
Processes
"High-intensity acoustic vibration is a new technology for solving the problem of uniform dispersion of highly viscous materials. In this study, we investigate the mixing characteristics of high-viscosity solid–liquid phases under high-intensity acoustic vibration and explore the effect of vibration parameters on the mixing efficiency."
Zhan, X., Yu, L., Jiang, Y., Jiang, Q., & Shi, T. (2023). Mixing Characteristics and Parameter Effects on the Mixing Efficiency of High-Viscosity Solid–Liquid Mixtures under High-Intensity Acoustic Vibration. Processes, 11(8), 2367. https://doi.org/10.3390/pr11082367
Preparation of NCh-B and NCh-B-Ti nanocomposites and their ignition and combustion performances
Energetic Materials Frontiers
"To overcome the agglomeration and insufficient combustion of nano-boron (n-B) powders, this study successfully prepared two novel types of boron-based nanocomposites using the acoustic resonance technology, namely high-substitute nitrochitosan/nano-boron (NCh-B) with ratios of 1:3, 1:5, 1:7 and 1:9, and nitrochitosan/nano-boron powder/nano-titanium (NCh-B-Ti) with Ti contents of 5 wt%, 10 wt%, 15 wt% and 20 wt%."
Xiong, Y., Wang, Y., Wan, C., Zhang, W., Qin, Z., Chen, S., & Xu, K. (2023). Preparation of NCh-B and NCh-B-Ti nanocomposites and their ignition and combustion performances. Energetic Materials Frontiers, 4(4), 247–253. https://doi.org/10.1016/j.enmf.2023.11.001
Difurazanopyrazine (DFP): A promising candidate for insensitive high explosive (IHE) application
"DFP was formulated with a variety of binders via resonant acoustic mixing and spray drying and pressed into pellets up to 98 % theoretical maximum density (TMD)"
Difurazanopyrazine (DFP): A promising candidate for insensitive high explosive (IHE) applications. (2023, June 22). https://meetings.aps.org/Meeting/SHOCK23/Session/V04.1
Parametric Effects on the Mixing Efficiency of Resonant Acoustic Mixing Technology for High-Viscosity Mixture: A Numerical Study
Processes
"Numerical investigations were conducted on the mixing efficiency of resonant acoustic mixing (RAM) technology using a high-viscosity mixture under vertically forced vibrations."
Khan, I. U., Guo, R., Farooq, U., Adhikari, S., & Zhou, H. (2023). Parametric effects on the mixing efficiency of resonant acoustic mixing technology for High-Viscosity Mixture: a numerical study. Processes, 11(1), 266. https://doi.org/10.3390/pr11010266
Manufacturing superfine AP by milling in a lab-scale resonant acoustic mixer (LabRAM)
Journal of Energetic Materials
"Small AP particles (≤15 μm) are difficult to obtain from commercial vendors due to restrictions derived from increased explosion hazards for superfine AP (SFAP). An in-house SFAP manufacturing process was devised herein using resonant acoustic mixing (RAM)."
Rodriguez, F. A., Thomas, J. C., & Petersen, E. L. (2023b). Manufacturing superfine AP by milling in a lab-scale resonant acoustic mixer (LabRAM). Journal of Energetic Materials, 1–13. https://doi.org/10.1080/07370652.2023.2219686
Effect of Resonant Acoustic Powder Mixing on Delay Time of W-KClO4-BaCrO4 Mixtures
Cornell University
"This study investigates the impact of resonant acoustic powder mixing on the delay time of the W-KClO4-BaCrO4 (WKB) mixture and its potential implications for powder and material synthesis."
Kwon, K., Ryu, S., Joo, S., Han, Y., Baek, D., Park, M., Kim, D., & Hong, S. (2023). Effect of resonant acoustic powder mixing on delay time of W-KCLO4-BACRO4 mixtures. arXiv (Cornell University). https://doi.org/10.48550/arxiv.2312.12798
A new ternary high-energy composite based on nano titanium powder with low sensitivity and stable combustion
Combustion and Flame
For solving the low combustion efficiency caused by aggregation and further promoting the application of nano titanium powder (n-Ti), a new ternary composite high-substitute nitrochitosan/nano titanium/graphene oxide (NCh/n-Ti/GO) was prepared by a resonant acoustic mixing method.
Wan, C., Guo, Z., Zhang, W., Chen, S., Qin, Z., & Xu, K. (2022). A new ternary high-energy composite based on nano titanium powder with low sensitivity and stable combustion. Combustion and Flame, 247, 112480. https://doi.org/10.1016/j.combustflame.2022.112480
Mechanical Characterisation and Cohesive Law Calibration for a Nitrocellulose Based–Cyclotetramethylene Tetranitramine (HMX) Polymer Bonded Explosive
Experimental Mechanics
The binder and the HMX crystals were mixed in the presence of a solvent using Resonant Acoustic Mixing (RAM) at a high temperature until the solvent evaporated.
Iqbal, M., Zhang, R., Ryan, P., Lewis, D., Connors, S., & Charalambides, M. N. (2022). Mechanical Characterisation and cohesive Law calibration for a Nitrocellulose Based–Cyclotetramethylene Tetranitramine (HMX) polymer bonded explosive. Experimental Mechanics, 63(1), 97–113. https://doi.org/10.1007/s11340-022-00895-x
The impact of resonance acoustic mixing on the production of solid propellants and explosives
Energetics Science and Technology
The second part provides a method for the equivalence of impact force in resonance acoustic mixing (RAM) and impact sensitivity data, which can convert the height data of the impact sensitivity into the corresponding impact stimulus force.
Ma, N., Chen, S., Zhang, Z., Sun, X., Xie, Z., Pang, W., & Zhang, G. (2022). The impact of resonance acoustic mixing on the production of solid propellants and explosives. In IOP Publishing eBooks (pp. 5–20). https://doi.org/10.1088/978-0-7503-3943-8ch5
3D Printing Energetics for Gun Propulsion Technology
The minerals, metals & materials series
...provides a method for the equivalence of impact force in resonance acoustic mixing (RAM) and impact sensitivity data, which can convert the height data of the impact sensitivity into the corresponding impact stimulus force. In the third part, the impact forces obtained in RAM and impact forces obtained from an impact sensitivity testing course are compared to evaluate the safety of the process.
Bird, D., Caravaca, E., Laquidara, J., Peabody, N., Houthuysen, C., & Ravindra, N. M. (2022). 3D printing energetics for gun propulsion technology. In The minerals, metals & materials series (pp. 211–221). https://doi.org/10.1007/978-3-030-92381-5_19
Continuous flow resonance acoustic mixing technology: a novel and efficient strategy for preparation of nano energetic materials
FirePhysChem
n this report, a novel strategy to enhance the mixing performance of fluid is developed by combining continuous flow microfluidic and resonant acoustic mixing (RAM) technologies. The results of the fluid visualization and 3D-Computational fluid dynamics (CFD) simulation showed that the new continuous flow resonance acoustic mixing (CFRAM) technology has better mixing efficiency than the traditional microfluidic approach.
Zhang, S., Zhan, L., Zhang, Y., Hou, J., & Li, B. (2022). Continuous flow resonance acoustic mixing technology: a novel and efficient strategy for preparation of nano energetic materials. FirePhysChem, 3(1), 29–36. https://doi.org/10.1016/j.fpc.2022.08.001
The surface activation of boron to improve ignition and combustion characteristic
Defence Technology
B coated with nano-Al or GF were prepared by acoustic resonance and solvent evaporation methods.
Wang, J., Wang, J., Mao, Y., Peng, R., & Nie, F. (2021). The surface activation of boron to improve ignition and combustion characteristic. Defence Technology, 18(9), 1679–1687. https://doi.org/10.1016/j.dt.2021.09.012
Styrene-Ethylene/Butylene-Styrene (SEBS) Block Copolymer Binder for Solid Propellants
Propellants Explosives Pyrotechnics
This paper reports on the production of two composite propellants made from a commercially-available-off-the-self polymer as binder by means of a resonant acoustic mixer (RAM) slurry process.
Wilkinson, P. J., Weaver, M. C., Kister, G., & Gill, P. P. (2021). Styrene‐Ethylene/Butylene‐Styrene (SEBS) block copolymer binder for solid propellants. Propellants Explosives Pyrotechnics, 47(1). https://doi.org/10.1002/prep.202100142
Evolution of HTPB/RDX/Al/DOA mixed explosives with 90% solid loading in resonance acoustic mixing process
Journal of Energetic Materials
Resonance acoustic mixing (RAM) technology is an attractive and safe mixing method for material mass and energy exchange... The density test of the cured sample further proved that the PBX was very uniform.
Cheng, W., Mu, J., Li, K., Xie, Z., Zhang, P., An, C., Ye, B., & Wang, J. (2021). Evolution of HTPB/RDX/Al/DOA mixed explosives with 90% solid loading in resonance acoustic mixing process. Journal of Energetic Materials, 41(4), 595–614. https://doi.org/10.1080/07370652.2021.2013992
Rational design of gradient structured fluorocarbon/Al composites towards tunable combustion performance
Combustion and Flame
PTFE/Al ink is prepared by acoustic resonance mixing to control rheological properties (viscosity and modulus) for 3D printing technology
Mao, Y., He, Q., Wang, J., Li, Z., Yang, Z., Nie, F., & Wang, D. (2021). Rational design of gradient structured fluorocarbon/Al composites towards tunable combustion performance. Combustion and Flame, 230, 111436. https://doi.org/10.1016/j.combustflame.2021.111436
Rocket Propellant Comparison: Conventional Planetary Mixing and Resonant Acoustic Mixing
Propellants Explosives Pyrotechnics
A standard HTPB/AP/Al composite rocket propellant formulation was prepared with a conventional vertical planetary action mixer and resonant acoustic mixer (RAM)... This result, therefore, indicates more thorough mixing in the case of the RAM process, but this requires confirmation...
Smith, P. C., Huf, J. P., & Williams, C. A. (2021). Rocket propellant comparison: Conventional planetary mixing and resonant acoustic mixing. Propellants Explosives Pyrotechnics, 47(1). https://doi.org/10.1002/prep.202100028
Primary Explosive Processing in the Resonant Acoustic Mixer
Propellants Explosives Pyrotechnics
“[RAM’s} ability to rapidly mix even highly viscous substances through application of acoustic energy while avoiding the use of traditional blades has provided substantial leaps forward in both safety and efficiency.“
Beckel, E., Oyler, K., Mehta, N., Khatri, N., Marin, J., Shah, A., Cordaro‐Gioia, E., Decker, R., Grau, H., & Stec, D. (2021). Primary explosive processing in the resonant acoustic mixer. Propellants Explosives Pyrotechnics, 46(5), 697–704. https://doi.org/10.1002/prep.202100008
Resonant acoustic mixing of polymer bonded explosives
Resonant acoustic mixing of polymer bonded explosives
The findings are then reconciled with wider literature observations and recommendations are made as how to best implement RAM for ‘PBneXt’ manufacture, ultimately allowing for explosive compositions with improved performance, mechanical, safety, and ageing properties.
Claydon, A. J. (2021). Resonant acoustic mixing of polymer bonded explosives. https://dspace.lib.cranfield.ac.uk/handle/1826/16337
Is ResonantAcoustic Mixing® (RAM) a Game Changer for Manufacturing Solid Composite Rocket Propellants?
Propellants Explosives Pyrotechnics
This study is a structured literature review of published ResonantAcoustic® Mixing (RAM) literature, considering the benefits and constraints of using RAM... Overall RAM offers numerous benefits to mixing existing and new materials with large savings in time, cost, improved safety and is more environmentally friendly
Wright, C. J., Wilkinson, P. J., Gaulter, S. E., Fossey, D., Burn, A. O., & Gill, P. P. (2021). Is ResonantAcoustic Mixing® (RAM) a game changer for manufacturing solid composite rocket propellants? Propellants Explosives Pyrotechnics, 47(1). https://doi.org/10.1002/prep.202100146
Combustion of Gelled HAN/Methanol/Water Propellants
Propellants Explosives Pyrotechnics
In the present work, an aqueous HAN/methanol solution (70.1 wt% HAN and 14.9 wt% methanol) was gelled with 1 wt% polyacrylamide in an acoustic mixer.
Ferguson, R. E., & Shafirovich, E. (2021). Combustion of gelled HAN/Methanol/Water propellants. Propellants Explosives Pyrotechnics, 46(11), 1672–1678. https://doi.org/10.1002/prep.202100166
Comparison of Propellant Processing by Cast‐Cure and Resonant Acoustic Mixing
Propellants Explosives Pyrotechnics
"For the propellant studied in this research, resonant acoustic mixing is a very promising, advanced processing technique that can be applied as an alternative to the conventional mechanical mixing of this high solid load propellant composition.“
Zebregs, M., Mayer, A. E. H. J., & Van Der Heijden, A. E. D. M. (2019). Comparison of propellant processing by Cast‐Cure and resonant acoustic mixing. Propellants Explosives Pyrotechnics, 45(1), 87–91. https://doi.org/10.1002/prep.201900169
Resonant Acoustic® Mixing: Processing and Safety
Propellants Explosives Pyrotechnic
“...technologies include additive manufacturing and Resonant Acoustic® Mixing (RAM), which are being demonstrated to reduce processing times, environmental impact and of course cost.”
Andrews, M. R., Collet, C., Wolff, A., & Hollands, C. (2019). Resonant Acoustic® Mixing: Processing and safety. Propellants Explosives Pyrotechnics, 45(1), 77–86. https://doi.org/10.1002/prep.201900280
Burning Rate Characterization of Ammonium Perchlorate Pellets Containing Nano-Catalytic Additives
AIAA SCITECH 2022 Forum
“Intimate contact between the AP (composite Ammonium Perchlorate) and nano-catalysts was ensured using a Resonant Acoustic Mixer (RAM).
Rodriguez, F. A., Thomas, J. C., Teitge, D., & Petersen, E. L. (2020). Burning rate Characterization of ammonium perchlorate pellets containing Nano-Catalytic additives. AIAA SCITECH 2022 Forum. https://doi.org/10.2514/6.2020-1425
Formulation via Resonant Acoustic Mixing at LANL
Formulation via resonant acoustic mixing at LANL
The possibility of an alternate method needed to be looked at to advance the process by expanding solvent choices, substrates, and reducing costs. Acoustic mixing had been shown to mix powders, slurries, pastes or even liquids.
Hartline, E., & Duque, A. (2020). Formulation via resonant acoustic mixing at LANL. https://doi.org/10.2172/1671064
Processing Studies of Energetic Materials using Resonant Acoustic Mixing Technology
Propellants Explosives Pyrotechnics
“...manufacturing methods within the energetics field can involve large amounts of solvents, long processing times, high waste output, high shear moving parts, and have single large batch limitations...manufacturing of energetic materials, propellants and pyrotechnics via RAM technology have highlighted many potential advantages.”
Davey, R. J., Wilgeroth, J. M., & Burn, A. O. (2019). Processing Studies of Energetic Materials using Resonant Acoustic Mixing Technology. Propellants Explosives Pyrotechnics. https://doi.org/10.1002/prep.201900355
Milling of Energetic Crystals with the LabRAM
Propellants Explosives Pyrotechnics
“...[confirms] feasibility of safely dry milling micron size energetic crystals on a LabRAM acoustic mixer while optimizing mill parameters to effectively reduce size.“
Kotter, L. N., & Groven, L. J. (2019). Milling of Energetic Crystals with the LabRAM. Propellants Explosives Pyrotechnics, 44(7), 908–914. https://doi.org/10.1002/prep.201800327
The Effects of Resonant Acoustic Mixing on the Microstructure of UHPC
International Interactive Symposium on Ultra-High Performance Concrete
“We study the effects of RAM on the microstructure of a designated UHPC mix...our results show that RAM mixing produces a dense UHPC matrix with low porosity.“
Vandenberg, A. & Wille, K., (2019) “The Effects of Resonant Acoustic Mixing on the Microstructure of UHPC”, International Interactive Symposium on Ultra-High Performance Concrete 2(1). doi: https://doi.org/10.21838/uhpc.9636
Meta-structure Enhancement of Resonant Acoustic Mixing via Embedded Additive Manufacturing
META-STRUCTURE ENHANCEMENT OF RESONANT ACOUSTIC MIXING VIA EMBEDDED ADDITIVE MANUFACTURING
"The performance of energetic materials is founded on a wide range of material and mixing parameters. Resonant acoustic mixing (RAM) is advantageous as a scalable, contactless energetics mixing method..."
Reach, W. A. (2019). META-STRUCTURE ENHANCEMENT OF RESONANT ACOUSTIC MIXING VIA EMBEDDED ADDITIVE MANUFACTURING. https://doi.org/10.13016/yk6h-qn3g
Evaluation of novel propellants manufactured from commercially available Thermoplastic Elastomers (TPE) using resonant acoustic mixing
Evaluation of novel propellants manufactured from commercially available Thermoplastic Elastomers (TPE) using resonant acoustic mixing
“The objective was to advance the current scientific understanding of the PSP relationships underlying RAM... it may be possible to tailor pre-mix meta-structure designs for targeted applications, providing promising new means [for RAM] to support industries that rely on energetics.”
Wilkinson, P. J. (2019). Evaluation of novel propellants manufactured from commercially available Thermoplastic Elastomers (TPE) using resonant acoustic mixing. https://dspace.lib.cranfield.ac.uk/handle/1826/15949
Determination and optimisation of Resonant Acoustic Mixing (RAM) efficiency in Polymer Bonded eXplosive (PBX) processing
Chemical Engineering and Processing - Process Intensification
An investigation into how the efficiency (time and energy required for homogeneity) of Resonant Acoustic Mixing (RAM) can be determined and optimised was undertaken. An idealised Polymer Bonded eXplosive (PBX) simulant based on glass microbeads (28.3 m D50, 62% v/v in binder and plasticiser) was used for mixing.
Claydon, A., Patil, A., Gaulter, S., Kister, G., & Gill, P. (2022). Determination and optimisation of Resonant Acoustic Mixing (RAM) efficiency in Polymer Bonded eXplosive (PBX) processing. Chemical Engineering and Processing - Process Intensification, 173, 108806. https://doi.org/10.1016/j.cep.2022.108806
New mixing technology achieves more explosive power
New mixing technology achieves more explosive power
Our engineers have achieved a 20 percent increase in munition explosive power by mixing current polymer bonded explosives using Resonant Acoustic Mixing (RAM) technology.
Brown, R. (2019, September 10). New mixing technology achieves more explosive power | newsroom | BAE Systems | International. https://www.baesystems.com/en/article/new-mixing-technology-achieves-more-explosive-power
Vibro-Engineering in Armaments
Extended Abstract
For instance... resonant acoustic mixing of propellants and pyrotechnics, oscillations of test bed in static evaluation of rockets, acoustic and non-acoustic combustion of propellants inside rocket motors, recoiling of gun during the firing of guns, generation of pressure waves in gun chamber during combustion / projectile motion etc., vibration remains an omni-present factor, influencing the product quality, performance, life and reliability
Murthy, K. P. S., High Energy Materials Research Laboratory, Defence Research and Development Organization, & Government of India, Ministry of Defence. (2021). Keynote speech: Vibro-Engineering in Armaments. In Extended Abstract. High Energy Materials Research Laboratory. https://static-01.extrica.com/conferences/delhi-2019/shri_kps_murthy_topic.pdf
Environmentally Sustainable Manufacturing for Energetic Formulations
Environmentally sustainable manufacturing for energetic formulations
In this research, we utilize Resonant Acoustic® Mixing (RAM) technology to generate secondary explosive pressing powder and cast-cure formulations that minimize the use of processing and cleaning solvents and reduce the amount of energetic scrap and waste.
Environmentally sustainable manufacturing for energetic formulations. (2022, June 6). https://serdp-estcp.mil/resources/details/dd31eb15-b719-4d96-a980-67cceed4b116
Future Sustainable Propellants
Future Sustainable Propellants
"... we used Resonant Acoustic Mixing (RAM) as an effective and efficient manufacture method.”
Wilkinson, P., P. Gill, P., & Kister, G. (2018). Future Sustainable Propellants. Future Sustainable Propellants. https://doi.org/10.17862/cranfield.rd.7346150.v1
Green Processing of Energetic Materials Using Resonant Acoustic Mixing Technology
Green processing of energetic materials using resonant acoustic mixing technology
This project will demonstrate the ability of the new Resonant Acoustic® Mixing (RAM) technology to produce energetic weapons systems components in a single processing step and quantify the reduction in processing waste generated as compared to legacy manufacturing techniques.
Green processing of energetic materials using resonant acoustic mixing technology. (2022, June 14). https://serdp-estcp.mil/projects/details/a908c05d-6590-4b32-ab8e-49c1cec1fa7a/wp-201507-project-overview
Chapter 6: Co-crystallization of Energetic Materials
Monographs in supramolecular chemistry
Novel techniques such as resonant acoustic mixing are introduced as a means for the large-scale production of energetic co-crystals.
Kennedy, S. R., & Pulham, C. R. (2018). Chapter 6. Co-crystallization of energetic materials. In Monographs in supramolecular chemistry (pp. 231–266). https://doi.org/10.1039/9781788012874-00231
Interactions of Polymers and Energetic Materials
Open Access Master's Theses
For calorimetry, foams were ground in a coffee grinder and sieved to particle sizes of 150-300 µm. They were mixed in a Resodyn Acoustic Mixer with pyrotechnic.
Levine, Rebecca M., "Interactions of Polymers and Energetic Materials" (2017). Open Access Master's Theses. Paper 1026. https://digitalcommons.uri.edu/theses/1026
Development of Energetic Formulations for Additive Manufacturing (2017 TechnicalInterchange presentation)
Resodyn Acoustic Mixers
EPEx1 (Extrudable Paste, Explosive 1) developed using LabRAM II... Use of RAM technology allowed high quality mixing at the small scales required.
Technical Interchange - Resodyn Acoustic Mixers. (n.d.). https://resodynmixers.com/technical-interchange-3/
Time for pairing: cocrystals as advanced energetic materials
CrystEngComm
In addition, resonant acoustic mixing (RAM) technique, bead milling and spray flash evaporation technique are also introduced as means for large-scale production of nanosized energetic cocrystals.
Zhang, J., & Shreeve, J. M. (2016). Time for pairing: cocrystals as advanced energetic materials. CrystEngComm, 18(33), 6124–6133. https://doi.org/10.1039/c6ce01239f
Formation of Additive-Containing Nanothermites and Modifications to their Friction Sensitivity
Journal of Energetic Materials
In the present work, MoS2, graphene, and hexadecane additives were dispersed in MoO3 prior to nanothermite
formation with the aim of reducing friction sensitivity. Nanothermites were subsequently prepared using a palmitic acid–passivated nano-aluminum (L-Al) and additive-containing nano-MoO3 by the resonant acoustic mixing of dry powders.
Kelly, D. G., Beland, P., Brousseau, P., & Petre, C. (2016). Formation of Additive-Containing Nanothermites and Modifications to their Friction Sensitivity. Journal of Energetic Materials, 35(3), 331–345. https://doi.org/10.1080/07370652.2016.1193072
Promising CL-20-Based Energetic Material by Cocrystallization
Propellants Explosives Pyrotechnics
A novel cocrystal (NEX-1) of CL-20 and MDNT is presented herein. The CL-20: MDNT cocrystal, obtained in high yield by resonant acoustic mixing, shows new properties versus the discrete components.
Anderson, S. R., Dubé, P., Krawiec, M., Salan, J. S., Ende, D. J. A., & Samuels, P. (2016). Promising CL‐20‐Based energetic material by cocrystallization. Propellants Explosives Pyrotechnics, 41(5), 783–788. https://doi.org/10.1002/prep.201600065
RAM Mixer Technology Controls Introduction and Control at Resonance (2016 TechnicalInterchange presentation)
Resodyn Acoustic Mixers
Swing example: Well-timed inputs of small energy will cause a swing to maintain or increase height. The energy is supplied by the person on the ground pushing on the swing as it moves away from them. Only small synchronized energy inputs are required to keep the swing going.
Technical Interchange - Resodyn Acoustic Mixers. (n.d.). https://resodynmixers.com/technical-interchange-3/
Putting the squeeze on energetic co-crystals: High-pressure studies of 2(CL20):HMX and NQ:DNP
High-pressure studies
Two energetic co-crystal systems have been investigated under pressure using neutron powder diffraction – 2(CL20):HMX, and nitroguanidine:2-hydroxy-3,5-dinitropyridine (NQ:DNP). The 2(CL-20):HMX co-crystal was prepared with a ResoDyn LabRAM Resonant Acoustic Mixer using a published method.
Hope, K. S., Ward, D. W., Lloyd, H., & Hunter, S. (2016, April). High-pressure studies of 2(CL-20):HMX and NQ:DNP. ResearchGate. https://www.researchgate.net/publication/301635819_Putting_the_squeeze_on_energetic_co-crystals_High-pressure_studies_of_2CL-20HMX_and_NQDNP
The Advantages of ResonantAcoustic Mixing (RAM) For Making Novel High-Energy Composite Materials
(2016 Technical Interchange Presentation)
Resodyn Acoustic Mixers
At NAWCWD we are using our LabRAM II nearly everyday.
Technical Interchange - Resodyn Acoustic Mixers. (n.d.). https://resodynmixers.com/technical-interchange-3/
Dry Powder Coating of Energetic Materials: Feasible or Futile? (2015 Technical Interchange Presentation)
Resodyn Acoustic Mixers
Capece and Davé used the acoustic energy produced by the RAM to deform a micronized polymer over the surface of ascorbic acid crystals, forming a continuous layer. Applying the same process to energetic materials is not a simple matter, and many factors must be considered to determine whether dry powder coating can be carried out without the risk of initiating the energetic material.
Technical Interchange - Resodyn Acoustic Mixers. (n.d.). https://resodynmixers.com/technical-interchange-3/
Resonant acoustic mixing: Its applications to energetic materials
resonant acoustic mixing and its applications to Energetic Materials
“[RAM] has several demonstrable applications to the field of energetic materials...”
Hope, K. S., Lloyd, H., Ward, D. W., & Michalchuk, A. A. L. (2015, April). (PDF) resonant acoustic mixing and its applications to Energetic Materials. ResearchGate. https://www.researchgate.net/publication/275340280_Resonant_Acoustic_Mixing_and_its_applications_to_energetic_materials
Macro and micro characterization of powder mixing processes
Macro and micro characterization of powder mixing processes
Resonant acoustic mixing significantly affected the final properties of lubricated blends, increasing their density with increases in acceleration and blending time. These changes in blend properties affected the final properties of tablets by increasing weight, decreasing hardness, and decreasing dissolution.
Osorio Caicedo, Juan Guillermo. Macro and micro characterization of powder mixing processes. Retrieved from https://doi.org/doi:10.7282/T3NK3CB1
Preparation of an energetic‐energetic cocrystal using resonant acoustic mixing
Propellants Explosives Pyrotechnics
“Resonant acoustic mixing (RAM) was applied to the preparation of an energetic-energetic cocrystal comprised of CL-20 and HMX in a 2:1 mol ratio. We have prepared the cocrystal using the RAM technology in a resource-efficient manner providing near quantitative yield. The cocrystalline product from the RAM preparation is consistent with the product from solution crystallization.”
Anderson, S. R., Ende, D. J. A., Salan, J. S., & Samuels, P. (2014). Preparation of an Energetic‐Energetic Cocrystal using Resonant Acoustic Mixing. Propellants Explosives Pyrotechnics, 39(5), 637–640. https://doi.org/10.1002/prep.201400092
The role of fuel particle size on flame propagation velocity in thermites with a nanoscale oxidizer
Propellants Explosives Pyrotechnics
“Acoustic mixing was better suited for this study due to the disparate differences between the materials...”
Sullivan, K. T., Kuntz, J. D., & Gash, A. E. (2014). The Role of Fuel Particle Size on Flame Propagation Velocity in Thermites with a Nanoscale Oxidizer. Propellants Explosives Pyrotechnics, 39(3), 407–415. https://doi.org/10.1002/prep.201400020
Thermal Imaging of Thermite Flame Propagation
Thermal imaging of thermite flame propagation
“The total mass of the powder was 1 g. The container was closed and mixed using a resonant acoustic mixer (LabRAM, Resodyn Corp.) at 100 G acceleration for a total of 2 minutes.“
Densmore, J. M., Sullivan, K. T., Gash, A. E., & Kuntz, J. D. (2014, January 17). Thermal imaging of thermite flame propagation - osti.gov. https://www.osti.gov/servlets/purl/1479055
An Examination of the Resonant Acoustic Mixer’s Flow Field
an examination of the resonant acoustic mixer’s flow field
This report details a second step made toward the high fidelity, first principles numerical simulation of the mixing for the resonant acoustic mixer. The current study addresses the mixing of two resins at higher, differing viscosities.
Nance, D. V. (2013, December). (PDF) an examination of the resonant acoustic mixer’s flow field. ResearchGate. https://www.researchgate.net/publication/326522386_An_Examination_of_the_Resonant_Acoustic_Mixer’s_Flow_Field
Effect of Solids Loading on Resonant Mixed Al‐Bi2O3 Nanothermite Powder
Effect of solids loading on resonant mixed al‐bi2o3
“...the performance and overall quality of [RAM] mixing was strongly correlated to the volumetric solids loading during processing; increasing volumetric solids loading decreases separation of particles, leading to more particle interaction and more intimate mixing.”
Nellums, R. R., Terry, B. C., Tappan, B. C., Son, S. F., & Groven, L. J. (2013, July 24). Effect of solids loading on resonant mixed al‐bi2o3 ... ResearchGate. https://www.researchgate.net/publication/263609052_Effect_of_Solids_Loading_on_Resonant_Mixed_Al-Bi2O3_Nanothermite_Powders
Feasibility Study and Demonstration of an Aluminum and Ice Solid Propellant
International Journal of Aerospace Engineering
Early mixtures in this work were mixed by hand or using a Ross DPM-1Q dual planetary mixer (Charles Ross & Son Company, Hauppauge, New York). However, inconstancies in mixing and packing densities motivated other approaches. A Resodyn LabRAM resonating mixer (Resodyn Acoustic Mixer Inc., Butte, Montana) was ultimately selected to mix the ALICE propellant.
Pourpoint, T. L., Wood, T. D., Pfeil, M. A., Tsohas, J., & Son, S. F. (2012). Feasibility study and demonstration of an aluminum and ice solid propellant. International Journal of Aerospace Engineering, 2012, 1–11. https://doi.org/10.1155/2012/874076
Processing Benefits of Resonance Acoustic Mixing on High Performance Propellants and Explosive
Processing Benefits of Resonance Acoustic Mixing on High Performance Propellants and Explosives
RAM can be used to effectively mix extremely viscous explosive formulations
Nelson, A., & Cross, T. (2012). Processing Benefits of Resonance Acoustic Mixing on High Performance Propellants and Explosives. Processing Benefits of Resonance Acoustic Mixing on High Performance Propellants and Explosives. https://apps.dtic.mil/dtic/tr/fulltext/u2/a597433.pdf
ResonantAcoustic ® Mixing; Design and Process Considerations Concerning Vessel/Case Geometry and Mix versus Cure Time When Preparing Composite Solid Propellant
ResearchGate
The mixing was performed using Resodyn Corporation’s ResonantAcoustic ® Mixers. These mixers employ acoustic energy for mixing and do not use any blades, or paddles. This capability enables mixing in the end use container and also allows the use of a wide variety of container geometries.
Miller, J. T., & Bode, D. A. (2010, December). ResearchGate. ResearchGate. https://www.researchgate.net/profile/Scott-Coguill/publication/270216392_ResonantAcoustic_R_Mixing_Design_and_Process_Considerations_Concerning_VesselCase_Geometry_and_Mix_versus_Cure_Time_When_Preparing_Composite_Solid_Propellant/links/54a2c3430cf267bdb9042682/ResonantAcoustic-R-Mixing-Design-and-Process-Considerations-Concerning-Vessel-Case-Geometry-and-Mix-versus-Cure-Time-When-Preparing-Composite-Solid-Propellant.pdf
Relevant Energetic & Pyrotechnic Patents
Approved and pending applications for work involving the use of ResonantAcoustic® mixing technology.
Method of obtaining firing pastes in an acoustic resonance mixers
FR WO WO2023156729A1 Sébastien Cuvelier, Julie Perouel & Nicolas Maroncelli Eurenco
Filed 2023-02-14 • Published 2023-08-24
The present invention relates to a method for obtaining a firing paste which comprises mixing the different ingredients constituting said paste in an acoustic resonance mixer. The invention also relates to a method for obtaining an ignition charge which comprises the deposit of the firing paste obtained according to the above method on a combustible support, and the drying of the combustible support.
Highlighted Use: A LabRAM was used to combine black powder and collodion.
Acoustic mixing system for creating propellant mixture
US US20210205770A1 Sarah L Bolden United States Government As Represented By The Secretary Of The Army
Priority 2019-09-12 • Filed 2020-09-14 • Published 2021-07-08
The present disclosure relates to a method of creating a propellant mixture. The method includes forming an explosive composition mixture, placing the explosive composition mixture into a mixing vessel assembly, and operating an acoustic mixing system at an operating frequency such that the acoustic mixing system causes
a vertical displacement of the mixing vessel. The explosive composition mixture has an explosive material, and one or more additives. The mixing vessel assembly has a closed mixing zone having a maximum vertical height. The acoustic mixing system is operated in a manner such that the operating frequency is substantially similar
to the resonant frequency and a ratio of the maximum vertical height of the closed mixing zone to the vertical displacement of the mixing vessel assembly is 2.0 or less.
Highlighted Use: A LabRAM II H powers a system that eliminate long processing times and wastewater
Improvements in or relating to energetic materials
WO EP US KR GB US20180305270A1 Kenneth Lewtas, Lewtas Science & Technologies Ltd
Priority 2015-10-12 • Filed 2016-10-12 • Published 2018-10-25
Energetic materials comprising active components, a polymer binder matrix and a tackifying resin are useful as propellants, fuels, pyrotechnic materials and explosives; the tackifying resin improves the adhesion and dispersion of the active components throughout the binder resin.
Highlighted Use: RAM technology mixed tackifying resin, active components and a binder matrix.
Propellant and Explosives Production Method by Use of Resonant Acoustic Mix Process
WO EP US US20100294113A1 Michael D. McPherson
Priority 2007-10-30 • Filed 2008-10-15 • Published 2010-11-25
A method to charge a container with an energetic mix is disclosed. This method includes the following steps: (a) adding a plurality of particulate energetic mix constituents and a binder to the container; and (b) mixing the plurality of energetic mix constituents utilizing a non-contact mixer to form a homogeneous mixture within
the container, and curing the binder to solidify the homogeneous mixture and bind the homogeneous mixture to the container. The container may be a liner or pre-form intended for insertion into a device, or may form a portion of the device itself, such as an aft portion of a rocket motor or casing for an explosive device. Because the resonant mixer does not have a moving impeller or other component that contacts the energetic mix and the container is not reused, there is minimal decontamination required between each mix and the manufacturer may rapidly commence assembling the next device, rather than clean-up and recertification.
Highlighted Use: RAM technology was able to coat a container with energetics.
Resonant acoustic mixing (ram) of an explosive composition
WO EP US AU CA US20200062669A1 Andy Oden Burn, BAE Systems PLC
Priority 2017-04-03 • Filed 2018-03-28 • Published 2020-02-27
The invention relates to a cast explosive composition, particularly to a pre-cure castable explosive composition comprising an explosive material, a polymerisable binder, a microencapsulated cross linking reagent, said microencapsulated cross linking reagent, comprising a cross linking agent encapsulated in a microcapsule. Providing a process for formulating a homogenous crosslinked polymer bonded explosive composition comprising the steps of:
i) forming an admixture of pre-cure castable explosive composition, said composition comprising an explosive material, a polymerisable binder, a microencapsulated cross linking reagent, said microencapsulated cross linking reagent, comprising a cross linking reagent encapsulated in a microcapsule; wherein the microcapsule, comprises at least one shell wall polymer, wherein the microcapsule’s shell wall polymer comprises at least one resonant acoustic stimulus labile linkage,
ii) applying resonant acoustic stimulus to the admixture, causing the microcapsule to rupture and release said cross linking reagent, to cause the cure process to start.
Highlighted Use: RAM technology begins the cure process for explosives.
Process for the preparation of composite pyrotechnic products
FR FR3090629A1 Marie Coquillat, Angeline Aumelas, Sebastien Gattini, Simon Kamatchy & Philippe Lescop
Priority 2018-12-20 • Filed 2018-12-20 • Published 2020-06-26
The present invention relates to a process for the preparation of a composite pyrotechnic product containing organic energetic charges of the nitramine type in a plasticized binder, this process comprising: a) the preparation of a crosslinked polymer of the polymer type with hydroxy terminal functions; b) the preparation of a mixture of organic energetic charges of the nitramine type and of a polyol having a melting temperature of less than approximately 50 ° C. and a molar mass of less than approximately 500 g / mol; c) mixing the products obtained in steps a) and b).
Highlighted Use: RAM technolgy distributes short polyol on the surface of energy charges
WO EP US US20210069662A1 Peter Andrew Lucon, Resodyn Corporation
GB GB2561172A Oden Burn Andy & Nicholas Stevens Matthew, BAE Systems PLC
Priority 2017-04-03 • Filed 2017-04-03 • Published 2018-10-10
A system for continuously processing a combination of materials includes a continuous process vessel having an outlet and one or more inlets. The continuous process vessel is configured to oscillate along an oscillation axis. An acoustic agitator is coupled to the continuous process vessel. The acoustic agitator is configured to oscillate
the continuous process vessel along the oscillation axis. An outlet passage is in fluid communication with the outlet. At least a portion of the outlet passage or at least a portion of the continuous process vessel is disposed within a portion of the acoustic agitator.
Highlighted Use: RAM technology allows for the processing of materials over a longer time.
A kind of solid-propellant pulps without slurry mixing preparation method and system
CN CN108043305A Lu Zhimeng, Wen Changyan, Zuo Juntao, Zeng Qinglin, Wang Qingsong, Sun Tao, Lu Yan, Beijing Aerospace Innovation Patent Investment Center & Hubei Hangpeng Chemical Power Technology Co Ltd
Priority 2018-01-03 • Filed 2018-01-03 • Published 2018-05-18
This application provides a kind of solid-propellant pulps without paddle mixing preparation method and system, including material to be mixed is put into mixing vessel by preset quality mixing vessel is fastened with acoustic resonance mixers mixing vessel and material to be mixed are heated
Highlighted Use: RAM technology combines materials while heating them up.
Non-conductive pyrotechnic mixture
EP US EP3683199A1 John Fronabarger, Jason Pattison & Robert Holderman, Pacific Scientific Energetic Materials Company
Priority 2019-01-16 • Filed 2020-01-02 • Published 2020-07-22
Described are energetic compositions formed of a 5,5’-bistetrazole salt and a perchlorate salt, in which the energetic composition is a co-precipitated product. The 5,5’-bistetrazole salt and the perchlorate salt can be dipotassium 5,5’-bistetrazole and potassium perchlorate. The energetic composition can have a particle size distribution between 1-50 micron and/or a mean volume diameter of less than 30 micron. In a low energy electro-explosive device, an ignition element is at least partially surrounded by an acceptor formed of this energetic composition, and the ignition element can be a bridgewire, a thin film bridge, a semiconductor bridge, or a reactive semiconductor bridge.
Highlighted Use: A LabRAM mixer was used to sieve and blend materials without static.
Cl-20:dnmt cocrystal crystal structure
US US20150361056A1 Jerry Salan, David J. Am Ende & Stephen R. Anderson, Nalas Engineering Services Inc.
Priority 2014-03-31 • Filed 2015-03-31 • Published 2015-12-17
A cocrystal of CL-20 (2,4,6,8,10,12-hexanitro-2,4,6,8,10,12-hexaazaisowurtzitane) and DNMT (1-methyl-3,5-dinitro-1,2,4-triazole) was formed through a resonant acoustic mixing process. The resulting cocrystal comprised an essentially 1:1 stoichiometric ratio between these coformers. The cocrystal advantageously has decreased sensitivity when compared with a pure CL-20 sample, and maintains thermal stability and comparable energetic performance.
Highlighted Use: RAM technology created a new, more stable but equally energetic crystal.
Energetics Folio
Energetics White Papers
UNMATCHED SAFETY
ENERGETICS MIXERS
LabRAM II H
1,000 gram capacity for energetics development
304L stainless steel housing and designed for remote operation. Rated for Class I Division I and Class II Division I material processing.
OmniRAM H
5 kg capacity for pilot-scale production
Onboard operating system with recipe development and memory, real-time parameter monitoring, 100% processing data retention, multiple operator security levels. RAM technology scales easily without additional testing from pilot to production scales.
RAM 5 H
36 kg capacity for pilot and production scale
Allows fast and efficient scale up from bench scale equipment with a full capabilities menu of temperature monitoring and control, mixing under vacuum, recipe development and retention, real-time parameter monitoring and recording, 100% processing data retention, multiple operator security levels, and product extraction options.
RAM 55 H
420 kg capacity for pilot and production scale
RAM 55 H’s batch payload capacity of up to 924 lbs (420 kg), digital control, and multiple processing capabilities multiply RAM’s value through direct and easy scale up from the bench development to larger scale batch production of energetic and hazardous materials.
